型號：Y0058-00
|
ZEN: 1.01.0596.0 | WAI: 54-8314 | Lester: 17132/17765 OEM NO: M191T12171, 2335420R10, E92Z11350A, F21418X25 |
||
| No Of Teeth:10 | Rotation:CW | Length (mm)：51 |
| Pinion O.D. (mm):31.7 | No Of Splines:8 | Pinion I.D. (mm):12 |
| Drive O.D. (mm):45.2 | ||
型號：Y0056-00
|
ZEN: 1.01.0595.0 | WAI: 54-8313 | Lester: 16874 OEM NO: M191T12071, 2331242670, 3132086030, Form Metal:61174 |
||
| No Of Teeth:8 | Rotation:CW | Length (mm)：44.5 |
| Pinion O.D. (mm):28,2 | No Of Splines:8 | Pinion I.D. (mm):12 |
| Drive O.D. (mm):43.5 | ||
型號：J0189B-00
|
ZEN: 1.01.0790.0 | WAI: 54-8133 | Lester: 16733 OEM NO: 211415507, 211485501, 2331210G00, 2331211M00 |
||
| No Of Teeth:9 | Rotation:CW | Length (mm):87 |
| Pinion O.D. (mm):36 | No Of Splines:10 | Pinion I.D. (mm):12 |
| Drive O.D. (mm):53 | ||
型號：J0189-00
|
ZEN: 1.01.0737.0 | WAI: 54-8104 | Lester: 16584 OEM NO: 21145006, 211455506, 8941155680, 23312H9100 |
||
| No Of Teeth:9 | Rotation:CW | Length (mm):87 |
| Pinion O.D. (mm):29.7 | No Of Splines:10 | Pinion I.D. (mm):12 |
| Drive O.D. (mm):53 | ||
型號：Q0086-00
|
ZEN: 1.01.0352.0 | WAI: 54-8304 | Lester: 16579 OEM NO: 23312-Y0511, M191T33371, 3132072031, H83381X45 |
||
| No Of Teeth: 8 | Rotation:CW | Length (mm):60 |
| Pinion O.D. (mm):28.2 | No Of Splines:4 | Pinion I.D. (mm):12.8 |
| Drive O.D. (mm):45.3 | ||
型號：Y0133-00
|
ZEN: 1.01.0616.0 | WAI: 54-8311 | Lester: 16889 OEM NO: M191T16071, 23300AA050, M191T17071, 23312AA010 |
||
| No Of Teeth: 9 | Rotation:CCW | Length (mm):64.5 |
| Pinion O.D. (mm):29.9 | No Of Splines:8 | Pinion I.D. (mm):12 |
| Drive O.D. (mm):45.2 | ||
型號：Q0041-00
|
ZEN: 1.01.0448.0 | WAI: 54-8100 | Lester: 16818 OEM NO: 212025001, 5-81123-0090, 23312V0601, 5-81123-015-0 |
||
| No Of Teeth: 9 | Rotation:CW | Length (mm):71 |
| Pinion O.D. (mm):35.8 | No Of Splines:12 | Pinion I.D. (mm):14.3 |
| Drive O.D. (mm):61 | ||
型號：Q0040-00
|
ZEN: 1.01.0499.0 | WAI: 54-8101 | Lester: 16774/16674 OEM NO: S114-320A, 211445504, 23312D0100, S114-320 |
||
| No Of Teeth: 8 | Rotation:CW | Length (mm):71 |
| Pinion O.D. (mm):35.8 | No Of Splines:12 | Pinion I.D. (mm):14.3 |
| Drive O.D. (mm):48 | ||
型號：Q0010-00
|
ZEN: 1.01.0144.0 | WAI: 54-8305 | Lester: 16588 OEM NO: M191T30971, 23312E3010, 22224722, M191T30171 |
||
| No Of Teeth: 9 | Rotation:CW | Length (mm):60 |
| Pinion O.D. (mm):29.52 | No Of Splines:4 | Pinion I.D. (mm):12.8 |
| Drive O.D. (mm):45.3 | ||
型號：J0095-00
|
ZEN: 1.01.0791.0 | WAI: 54-8132 | Lester: 16803 OEM NO: 23312M4902, 23300M4900, 211435507, S114-252 S114-393 |
||
| No Of Teeth: 8 | Rotation:CW | Length (mm):87 |
| Pinion O.D. (mm):28 | No Of Splines:10 | Pinion I.D. (mm): |
| Drive O.D. (mm):53.2 | ||
